Auto-rewind Hose Reel

NIOSH approved with Standard Yellow Hoze

The Respirex automatic re-wind hose reel has been designed to provide a safe, convenient and efficient way to deploy air hose where required. Constructed in high impact UV stabilized polypropylene for all-purpose corrosion free durability, the hose reel can be installed indoors or out.

At an average weight of just 10 kg (22 lb) including hose, these reels are ideally suited for fixed position applications or for use as portable hose packs. All reels are supplied with hose ready for easy installation. A simple mounting bracket is included for wall or overhead positioning which allows the reel to swing through up to 270º or to be fixed centrally.

An equally simple optional bench or floor mount is also available. Both brackets feature a padlock facility to secure the reels in place. The automatic re-wind hose reel reduces the possibility of accidents and helps to improve the working environment. The user pulls out the length of hose required which is then automatically rewound after use. In addition to neat and tidy storage, the loose effort re-wind tension makes the automatic re-wind hose reel safe and easy to use even with the hose fully extended.

A two-position switch provides latching of hose at 0.5m intervals or a free run of hose for maximum convenience.

Important Notes

Maximum hose lengths: - yellow 3/8" bore hose - 15m. - green heavy duty 3/8" bore hose - 10m. Side entry supply hose to the reel is heavy duty green 3/8" bore at 1.5m in length.
